Backtracking High Performance Automatic Solar Tracker System
Product info:
Single axis automatic solar tracker can maximize your solar system's electricity production by directing your panels to follow the sun, which optimizes the angle at which your panels receive sunlight radiation.
Solar trackers are great land optimization tools as they can generate more electricity than their fixed tilt counterparts while consuming the same amount of land space.
Advancements in technology and advanced electronics have drastically reduced maintenance concerns for tracking systems.
Advantages:
1. Minimum O&M work due to the reduced amount of component, simplicity and robustness.
2. Lubrication free rotation elements.
3. Backtracking Algorithm, avoiding shadows and increasing production.
4. Easy integration into the plant’s communications system
5. Wireless communication system with Zigbee®.
6. Remote monitoring and predictive maintenance.
7. Wide range of motion: 120° (± 60°).
8. Minimum energy consumption.
9. Preassembled joints and components.
10. Minimum installation time, fast & simple.
11. 100% bolted connections. No drilling, cutting, or welding on-site.
High tracking accuracy, average tracking accuracy is ≤1°
Technical Parameters of Backtracking High Performance Automatic Solar Tracker System
| Technical Parameters |
| Tracking Range | 士 60° |
| Driving System | Slew drive, 24VDC motor |
| Modules per Tracker | Max.90 modules per tracker |
| System Voltage | 1000 V or 1500 V |
| Structure Material | Hot dipped galvanized/Pre-galvanized steel |
| Power Supply | Powered by PV strings,back-up lithium battery |
| Module Supported | All commercially available modules |
| Operation Temperature | -30℃ - 60℃ |
| Control Algorithm | Astronomical algorithms + Tilt sensor close loop |
| Backtracking | Yes |
| Night Position | Yes |
Classification:
Popular solar trackers in the market has 3 types:passive, active and open loop trackers which is distinguished from drive and sensing or positioning system that they incorporate.
Passive trackers: The tracker has a gas sensing device and the tracker will move across the sky by using suns radiation to heat gases.
Active trackers: The tracker has an electric or hydraulic drives and some type of gearing or actuator. Good future 1P single row solar panels tracker belongs to this type of active trackers. It’s also the most popular type in the market right now.
Open loop trackers: Use no sensing but instead determines the position of the sun through pre-record data for a particular site.
